- Store up to 25 tags
- Two tags supplied (card-type)
- Coil can be mounted away from the board (up to 5m) for higher security
- Relay output: max. 3A/24V
- Power supply: 12VDC/100mA
- Skill Level: Kit Basic Soldering Required
- store up to 25 tags
- excellent security: 64-bit coded
- Unlimited # of tags in low-security mode
- two tags supplied (card-type)
- Easy addition and removal of tags
- Output activation: 0.5s to 4min or toggle (ON/OFF)
- Coil can be mounted away from the board (up to 5m) for higher security
- applications:
- open doors, fences, gates, etc...
- arm/disarm security systems in homes / offices / vehicles etc...
- Prevent unauthorised use of equipment, machinery, computer systems etc...
- automate cat doors...
- options:
- HAA86C/TAG: optional acces card
- HAA86C/TAG2: optional acces badge
Specifications:
- EM4100 compatible
- relay output: max. 3A/24V
- power supply: 12VDC/100mA
- dimensions: 66x62x20mm / 2.6x2.4x0.8"
